Deltoid ligament injury



MaisonDeltoid



Etiology



Ankle sprain

- eversion / External rotation



Ankle fractures

- up to 40% of ankle fractures have deltoid ligament injury

- slightly more common to injure deltoid ligament than fracture medial malleolus

- supination / external rotation (Type IV)

- pronation  / external rotation (Type IV)



Epidemiology



5% of ankle injuries involve the deltoid ligament



Anatomy



Superficial layer Deep layer
Limits external rotation Limits eversion

4 components

- tibion-navicular

- tibio-spring ligament

- tibio-calcaneum

- tibio-talar

2 components

- posterior tibiotalar

- anterior tibiotalar



Spring (calcaneonavicular) ligament

- sustenaculum talus to navicular

- fibrocartilage component articulates with head of talus



Symptoms / signs



Medial pain and tenderness



Xray



Syndesmotic injury with high grade deltoid injury



deltdelt

Ankle dislocation with soft tissue injury to Deltoid and syndesmsosis



Ankle fractures with deltoid ligament rupture / Bimalleolar equivalent injury



MaisonMaison

Maisonneuve injury with proximal fibular fracture and increased medial clear space



DeltoidDeltoid

Weber B with increased medial clear space on CT



Weber CWeber C

Weber C with increased medial clear space



Stress xrays



External rotation / valgus stress views

Gravity stress views



MRI



DeltoidDeltoid



DeltoidDeltoid



Indications for deltoid ligament repair



1. Failure to obtain adequate reduction of medial clear space



Deltoid ligament may be blocking reduction

Anchor repair of deltoid ligament to tibia or talus



2.  Full thickness deltoid ligament injury with anatomical reduction



Guo et al PLoS One 2021

- meta-analysis of operative versus non operative deltoid ligament repair

- 400 patients with ankle fracture

- deltoid repair had better reduction, and better functional outcomes

- mostly low quality studies. Only one RCT which showed no functional difference



Technique



Vumedi open deltoid ligament repair



Arthroscopic technique deltoid ligament rupture



Chronic medial ankle instabilty / chronic deltoid ligament insufficiency



Symptoms



Medial pain

Instability



Signs



Increased valgus instability



Xray



Deltoid

Old bony avulsion of deltoid ligament



Operative management



Deltoid ligament reconstruction +/- syndesmotic fixation



Surgical technique PDF



Results



Pellegrini et al Foot Ankle Surg 2019

- 13 cases of chronic deltoid ligament insufficiency

- direct repair with internal brace

- scores increased from 59 to 75

- 2 implant failures
