Aquired Adult Flatfoot Deformity

Definition



Acquired Adult Flatfoot Deformity (AAFD)

- collapse of medial longitudinal arch

- secondary to ligament / tendon / joint or bony pathology



Classification



1. Congenital



Flexible / Physiological



Ligamentous Laxity (DIAL HOME)



Rigid

- Congenital Vertical Talus

- Tarsal Coalition



2.  Acquired



Tibialis Posterior Dysfunction



RA Flat Foot



Neurological

- Charcot Foot

- spinal dysraphism

- CP

- polio



OA



Midfoot OA / Lis Franc injury



Midfoot OA Planovalgus



Subtalar joint OA (calcaneal fracture)

Ankle OA



Ankle OA Valgus Tilt



Ligament

- isolated spring ligament rupture (rare)

- iatrogenic / traumatic plantar fascia rupture (rare)



Compensory to Rotational & Coronal plane deformities

- tibial torsion

- genu valgum

- ankle equinus 2° tight TA



Biomechanics of FlatFoot



Normal Gait / 3 phase rocker



1.  Heel Strike



Tibia IR



Hindfoot Everts

- unlocks TNJ & CCJ

- forefoot pronates



Allows shock absorption by hind/mid/forefoot



2.  Stance

- WB axis passes through ASIS to patella to middle of foot



3.  Toe Off



T Posterior "locks" the midfoot (i.e. the transverse tarsal joints)

- T Anterior inverts the hindfoot

- T Achilles plantar flexes the calcaneum

- Tibia externally rotates



Flatfoot Gait



The above components are exaggerated

- More stress on ligament structures



WB axis shifts medially, causing

- increased femoral anteversion

- internal knee rotation

- increased Q angle



T Achilles becomes evertor



Increased pronation

- may cause Hallux Valgus



Specific Conditions



Lisfranc Joint OA



Acquired Adult Flatfoot



Aetiology



1.  Post injury



Degenerative arthritis develops after fracture dislocation

- Acute injury often missed

- Adequate acute treatment may not prevent occurrence



2.  Idiopathic

- not related to trauma



3.  Charcot



X-ray



Degenerative changes invariably involve second MT/ 2nd Cuneiform joint

- may involve 1st & 3rd joints

- rarely involves 4th & 5th joints



Midfoot AP Secondary to Missed Lis Franc



Non-operative



Moulded arch support / UCBL initially if correctable

Lateral Single Upright caliper with Medial T strap if not



Operative



Realignment of Lisfranc joint with arthrodesis



Rheumatoid Flat Foot



50% will get flat foot

- subtalar OA

- spring ligament attenuation

- tibialis post dysfunction

- progressive valgus deformity at hindfoot



OA of Ankle Joint



Usually post traumatic

- valgus tilt of Talus leads to pronation of Talus & Calcaneus



Flatfoot def corrected when AJ realigned



Charcot Flat Foot



90% changes in hind and midfoot

- repetitive microtrauma in presence of neuropathy leads to microfracture

- 2° to Sensory & Autonomic Neuropathy



Progressive subluxation / collapse



Usually associated with Diabetes

- may be marked collapse

- develop bony prominence on medial sole

- may cause ulceration



Plantar Fascia Rupture



Traumatic or spontaneous

- pain at calcaneal origin

- palpable gap

- often 2° excess HCLA



Management

- arch support

- longitudinal arch will slightly flatten, but rupture should heal



Spring Ligament Rupture



Rare

- ? Repair

- probably in reality treat as for PTTD
