Arthrodesis

IndicationsHip Fusion



Young adult

- 16 - 30 years old

- monoarticular disease

- heavy demand



Exhausted options of osteotomy

- risk of THA failure  / multiple revision surgeries considered too high



Aims of arthrodesis



Maximise bony contact

Minimise shortening

Provide rigid internal fixation

Compress the fusion site

Facilitate future conversion to THR



Contraindications



AVN

- difficulties in obtaining arthrodesis without femoral bone stock



Poor bone stock due other causes



Bilateral hip disease

- need ROM in other hip 90o

- in order to compensate in gait



Polyarticular disease eg Rheumatoid arthritis

- likely to develop hip / knee / back OA



Degenerative disc disease

- lumbar spine ROM important to compensate in gait and ability to sit in chair



Stiff ipsilateral knee or contralateral hip



Advantages



Good pain relief



No activity restriction

- most patients employed

- can return to normal jobs, even heavy labour

- most able to walk > 1 mile



Long term solution c.f. THA



Disadvantages



Functionally inferior to THA



Increased stress on other joints



1.  Lumbar spine

- 50% back pain

- most common reason for converting to THR



2.  Ipsilateral knee

- 50% knee pain and instability

- increase rotation demanded in knee due to arthrodesis



3.  Contralateral hip

- has to compensate with increased ROM

- may predispose to OA

- will certainly worsen any underlying arthritis



Difficulties with certain activities



Squatting

Supine sex

Running

Sitting erect in chair

Difficulty putting on shoes



Gait abnormalities



Increased energy requirements

- increased oxygen consumption

- gait 50% less efficient



Increased lumbar lordosis to compensate

- decreases stride length

- shortened stance phase

- contralateral hip has increased mobility compared to normal



Surgery



Concepts



To retain option of conversion to THR

- don't use pelvic osteotomy

- preserve abductors



Types



1.  Intra-articular

- most common

- allows disease to be addressed

- better correction of deformity

- difficult in paediatrics due to large amount of cartilage present



2.  Extra-articular



3.  Combined

- usually use combination



Position



Sagittal / 25° flexion

- <20° flexion - difficult to sit

- >25° flexion - difficult to walk due to LLD



Coronal / 5° adduction

- never abduction: can't walk, fall over even with 5° abduction

- too much adduction: LLD



Rotation / 15° ER



< 2 cm LLD



Complications



Pseudarthrosis - 10%

Mal-positioning



Methods to Increase Union



1.  Inter-trochanteric / subtrochanteric osteotomy

- can increase union rate by decreasing lever arm of abductors

- come back 6/52 later and fix intertrochanteric fracture



2.  Vascularised bony extra-articular method

- iliac crest with Tensor Fascia Lata still attached

- the graft is inserted into trough in the anterior joint



Options



1.  Lateral cobra plate

- detach GT

- pelvis to femur

- nil pelvis osteotomy



Hip Fusion Cobra Plate



2.  DHS

- Sunderland method



Hip Fusion APHip Fusion Lateral 2



3.  Anterior plating

- Smith Peterson approach



4.  Double plating

- anterior and lateral plate



Sunderland Method



Intra-articular approach /  2 hole DHS



Technique



Radiolucent table with II

- supine



Smith Peterson approach

- leave abductors intact

- dislocate hip anteriorly

- between sartorius and TFL

- between G medius and Rectus Femoris

- take off reflected head



Remove cartilage from head & acetabulum

- cup arthroplasty instruments useful

- approximate raw surfaces

- pack cancellous autograft

- position hip & hold with guide-wires temporarily

- place one guide wire central in head



Check position of hip

- need to be able to do intra-operative Thomas test

- FFD 25o / Add 5o / ER 15o



Fix with 150° DHS

- through joint into thick supra-acetabular area of ilium

- supplement with additional screws as necessary

- +/- Sub-Trochanteric Osteotomy



Spica at 2/52 for final position

- NWB until xray union union



Schneider Technique



Previously very popular technique

- don't use now as THR conversion not possible



Characterised by pelvic osteotomy

- increases surface area for fusion

- pelvic osteotomy compromises future THR conversion



Femoral head compressed into osteotomised pelvis

- Lateral Cobra plate fixed to pelvis



Kostuik



Lack of head technique

- for post AVN or failed THR

- using a lateral Cobra plate & inserting the neck into the acetabulum



Lateral approach with GT osteotomy

- reflect abductors cephalad

- denude acetabular cartilage

- apply lateral cobra plate

- fix the GT to the arthrodesis with screws and place graft at the site

- +/- anterior plate



Britian Technique



Extra-articular arthrodesis

- ischio-femoral arthrodesis

- oblique subtrochanteric osteotomy

- place tibial cortical graft from inferior femur to osteotomy in ischium

- medialize femur on graft

- spica



Results of Arthrodesis



Sponseller JBJS 1984 (classic report)



53 patients at 20 years post fusion

- average age 14 years

- back pain 60% / similar incidence back pain to general POP

- ipsilateral knee pain 40%

- contralateral hip 20%

- pain was unrelated to length of arthrodesis

- high functional abilities / played sport

- knee laxity of MCL was common 2° to hip excesssive adduction in fusion

- 15% conversion to THR (for back or knee pain)



TKR with fused Hip



Technically difficult

- have knee over edge of bed

- only way to get high flexion of knee for insertion tibial prosthesis



Poor results

- poor ROM



Best to revise arthrodesis first

- not if abductors not functioning



Conversion to THR



Indication

- back pain main indication

- ipsilateral knee pain

- contralateral hip pain



Issues



1. Abductors

- adequate function related to good outcome

- test by palpation preoperatively



2. Reason for fusion ?infection



3. Bony loss at acetabulum & femur



4. LLD

- average 2cm



5. Skin



6.  Higher failure than 1° THR



Results



Good relief of LBP

- less so hip and knee

- most patients happy

- hip scores change little (owing to good results from arthrodesis)



LL equality achieved



Improved ROM



Gait poor for a couple of years

- related to abductor function

- intensive physio required



Survival

- 80% 10 year

- increased risk of infection
