Principles of External Fixation

Indications



Acute / damage control

- compound injures

- periarticular injuries

- high energy injuries / let soft tissues settle

- multi-trauma (avoid second hit)



Chronic / definitive management

- mal /non union

- infection

- deformity

- LLD



Problems



Pin site infections

Malunion

Non union



Construction



Pins



Diameter

- < 1/3 diameter of bone

- 3, 4, 5 mm



Materials

- stainless steels

- titanium

- HA coated



Bars



Increased diameter

- increased strength and rigidity



Clamps



Modular, multidirectional

- pin to bar

- bar to bar



Frame types

- uniplanar

- biplanar

- circular

- hybrid (combination of planar + circular)

- joint spanning (non or articulated)



Increasing strength / stiffness



Increase pin diameter

Increase number of pins

Increase pin spread on same side of fracture

- near / far / near / far



Decrease distance of bar to bone

Increase number of bars



Note:  Increasing stiffness can lead to non union

- to increase union rates

- reduce stiffness

- i.e. reduce above factors



MRI issues



Non compatible

- local heating

- production of current

- costly disruption of MRI machine

- interference with pictures



Healing



1.  Rigid inter-fragmentary fixation

- intramembranous ossification



If a frame is too rigid

- osteopenic nonunion

- need to reduce rigidity

- may need bone graft



2.  Micro-motion / strain

- collagen formation and endochondral ossification



If a frame is too loose

- excessive callous

- hypertrophic non union



Types



Ankle External Fixation



Fracture blisters 1Fracture blisters 2



Ankle Ext Fix 1Ankle Ext Fix 2Ankle Ext Fix 3
