Hip Dislocation

IncidencePosterior Hip Dislocation



Young men



Posterior / Anterior 9:1



Aetiology



High velocity injury

- head direction at impact decides direction of dislocation



Anterior Dislocation



Externally rotated & abducted leg

- flexion = inferior dislocation

- extension = pubic dislocation



Posterior Dislocation



Axial compression of adducted leg

- more flexion causes pure dislocation without fracture



Anatomy



Inherently stable joint

- large head on smaller neck

- allows deep seating of femoral head

- acetabulum deepened by labrum

- capsule reinforced by ilio/pubo/ischio femoral ligaments



40% femoral head in contact with articular cartilage

10% in contact with labrum



Blood supply



Majority by deep branch of Medial Circumflex Femoral Artery

- minimal by medial epiphyseal artery via ligamentum teres

- little to non via LCFA



MCFA

- arises medial aspect of profunda

- along posterior intertrochanteric crest extracapsular / back of femoral neck

- passes between iliopsoas and pectineus medially

- runs along inferior border of obturator externus, above adductor brevis

- deep to quadratus femoris

- emerges between quadratus and inferior gemellus

- runs over conjoint tendon (2 gemelli and obturator internus)

- then penetrates capsule between conjoint and piriformis

- runs along superior aspect of neck to femoral head



Transverse branch (to ischium) and ascending branch (to trochanteric fossa0

- arise anterior to quadratus



Must protect this deep branch MCFA in a posterior approach



With dislocation and capsular tears

- some ascending cervical branches stretched/kinked

- emergent reduction can improve blood flow to femoral head



Associated Injuries



50-95% have other injury



Acetabular fracture



Femoral head fracture / Pipkin fracture



Sciatic nerve 10% / posterior dislocation



Patella fracture



PCL



Femoral artery injury - anterior dislocation



Femoral shaft fracture

- reduce head via steinman pin in proximal fragment

- then IMN femur



Classification



Direction



1. Medial / Central

- really medial displacement with acetabular fracture



2. Anterior

- pubic / obturator / perineal



3. Posterior



Posterior Hip Dislocation Lateral



Pathoanatomy



Capsule & Ligamentum teres torn



Labral tears & muscular injuries also occur



Y / iliofemoral ligament often intact with posterior dislocation

- blocks reduction

- bony fragments also block reduction



Clinical Features / Xray



Posterior dislocation

- leg shortened, flexed, adducted & internally rotated

- head small on xray



Posterior Hip Dislocation



Anterior dislocation

- leg short and externally rotated

- head larger on xray



Check NV status / sciatic nerve



Management



Immediate



Assess & manage life threatening injuries

- EMST / ATLS principles



Principles



1. Emergent reduction

- closed +/- open

- reduce risk AVN



AVN

- < 6 hours 10%

- 20% - 50% if >24 hours



2.  Assess stability



Posterior wall fracture > 40%

- need ORIF for stability



Hip Dislocation Posterior Wall FractureHip Dislocation Posterior Wall Fracture



Posterior wall fracture < 40%

- can be unstable

- EUA after reduction to assess stability

- should be able to flex to 90o and some IR without instability



3. Screen for retained fragments



Compulsory CT

- xray will not detect fragments < 2mm



Hip Dislocation Loose Body



Remove / ORIF depending on size of fragment and location / Pipkin type



4. Reconstruct acetabulum if unstable or incongruent



Closed Reduction Posterior Dislocation



Technique



Full muscle paralysis on radiolucent table

- supine

- assistant places downward pressure on ASIS

- operator up on bed grasping leg

- flex hip to 90o, flex knee to 90o



Technique

- ER head around acetabulum / axial traction or

- IR head around acetabulum / axial traction



Post reduction

- check concentric reduction on II

- check stability in flexion



Unstable reduction

- skeletal traction / femoral steinman pin



Post op



NV examination when patient awake

- ensure sciatic nerve working

- ensure hasn't become entrapped with reduction



CT



Closed Reduction Anterior Dislocation



Technique

- as above

- traction in line with femur flexed

- internal rotation maneuver



Irreducible Dislocations



Incidence

- 2-15%



Causes



1.  Capsule / Labrum / Ligamentum teres

2.  Muscle interposition

- anterior usually rectus / psoas

- posterior usually piriformis / G maximus

3. Bone fragment

4.  Muscle tone

- patient requires relaxant



Management



Open reduction



Non-concentric Reduction



Esssential to obtain X-ray and CT after reduction



X-ray

- head - teardrop distance must equal contralateral side



CT

- only with CT can < 2mm fragments be seen



Pipkin Infrafoveal CT



MRI

- may be needed to see labral tears blocking reduction



Open reduction



Indications



1.  Irreducible dislocation



2.  Non-concentric reduction

- loose bodies / interposed tissue



3.  Post operative sciatic nerve palsy



4.  Unstable posterior acetabular fracture



5.  Associated NOF fracture



6.  ORIF Pipkin fracture



Approach



Usually from direction of dislocation

- preserve intact capsule

- preserve remaining blood supply

- i.e. with posterior dislocation the posterior capsule will be torn

- provides entry into joint



Posterior Approach



Aim to preserve intact anterior capsule and blood supply

- beware sciatic nerve

- divide piriformis and conjoint tendon away from insertion to preserve deep branch MCFA

- may need to extend posterior capsular rent

- allows direct visualisation of blocks to reduction

- blocks include G. max, piriformis, capsule, bony fragments

- may need to excise ligamentum teres

- explore acetabulum for loose bodies

- close capsule afterwards

- may need to excise L Teres



Other issues



Posterior acetabular fracture

- ORIF if > 40% or unstable



Pipkin fracture

- manage as per Femoral Head Fractures



Subcapital fracture

- Watson Jones / Smith Peterson approach

- supplementary lateral approach to insert fixation



Post Operative



NWB for 6/52



Bone scan re vascularity



Issue

- °AVN = FWB

- AVN = consider bisphosphonates



Yue et al J Orthop Trauma 2001

- 5/54 low blood flow on early SPECT

- no correlation with AVN



Complications



AVN



Related to

- time to reduction <12/24

- velocity of injury

- open reduction vs closed (x4)

- direction (anterior < posterior)



Timing

- < 6/24 = 2-10%

- > 12/24 = 52%



Direction

- posterior 17%

- anterior 2%



Tends to be localised

- revascularisation occurs on reduction

- damage to lateral & medial epiphyseal artery

- metaphyseal blood supply remains

- occurs in first 18 months



OA



Incidence

- 15 - 20 %



Causes

- AVN

- instability

- incongruous reduction

- cartilage damage at time of dislocation



Philippon et al Arthroscopy 2009

- hip arthroscopy post traumatic dislocation in 14 athletes

- all had chondral defects, 11 had loose fragments

- all patients had labral tears



Sciatic Nerve Palsy



Posterior dislocation

- 8 - 19%

- more common after fracture / dislocation



Type

- usually partial CPN

- usually resolves



Only explore if onset after MUA



Else observe



Instability < 1%



Myostitis Ossificans



Uncommon

- usually little functional problem
