CT Scan

Principle



Irradiate a slice of tissue from multiple angles



Measure the output from different sides



Tissues have different densities

- with denser tissue fewer x-rays reach the detectors



Hounsfield scale



Bone    2000

ST        40

Water   0

Fat       -100

Air       -1000



Settings



Grey scale

- eye can only see 11 different shades



Adjust settings to bone or soft tissue



Osteoblastoma Soft Tissue CTOsteoblastoma Bone Window



Multislice



Multiple detectors at any one time

- increase amount of data acquired in a single slice

- increased speed

- reduces artefact



Slice thickness



Decreased slice thickness

- increased info

- increased radiation



Reconstruction



Axial

Sagittal

Coronal



Axial Spine CTSagittal CTCoronal CT



3D



3D CT Reconstruction3D CT Hip



Radiation dose



CXR                 1

Pelvis               35

CT Chest          400

CT Abdo/pelvis  500
