Distal Tibial Fractures

Distal Tibial Fractures



Definition



Metaphyseal

Extra-articular



Distal Tibial Fracture



































Intra-articular Extension



Posterior Malleolar Fractures

- occult in 70%

- especially with spiral distal tibial fractures



Distal Tibia Intra-articularDistal Tibia Intra-articularDistal tibia CTDistal tibia CT



Distal tibia Distal tibia 2Distal tibia 3Distal tibia 4



Wang et al. J Orthop Surg Res 2021

- systematic review

- incidence 70% occult fractures

https://pubmed.ncbi.nlm.nih.gov/34074309/



Nonoperative Management



Tibial Shaft Fracture Non Operative Treatment BeforeTibial Shaft Fracture Non Operative Treatment After





Operative Management



Options



1. Temporary external fixator

2. IM Nail

3. Plate



Temporary External fixation



Indications

- significant swelling

- significant displacement / non controlled in cast

- significant wounds, need for soft tissue coverage



Technique

- two pins proximal tibia

- trans-calcaneal pin



AO Trauma Ankle Bridging Delta Frame

https://surgeryreference.aofoundation.org/orthopedic-trauma/adult-trauma/distal-tibia/partial-articular-split-depression-fracture/temporary-joint-bridging-triangular-external-fixation#principles-of-joint-bridging-triangular-external-fixation



Distal Tibial Fracture DisplacedDistal Tibial Fracture External FixationDistal Tibial Fracture ORIF



Nail v Plate



Liu et al. Orthop Surg 2019

- meta-analysis of 10 RCTs, 911 patients

- no difference in nonunion, delayed union, or time to union

- reduced incidence of malunion with MIPO plate

- reduced wound problems with nail

https://pubmed.ncbi.nlm.nih.gov/31823496/



Intra-medullary Nail



Distal Tibial FractureDistal Tibial Nail APDistal Tibial Nail Lateral



Indications

- wounds / soft tissues not suitable to plate

- relatively stable

- sufficient distal bone



Design



Distal tibial nails

- multiple distal screws

- usually 2 medial-lateral and 1 AP

- most distal screw within 5 mm of end of nail



Smith & Nephew Tibal Meta Nail

https://www.smith-nephew.com/global/surgicaltechniques/trauma/trigen_meta_instrument_01361v10114_us.pdf



Vumedi nail video

https://www.vumedi.com/video/distal-tibia-nailing-when-how/



Technique



Consider semi-extended suprapatella nail

- easier to reduce fracture

- easier to get AP and lateral fluoroscopy



Most important is to centre guide wire over talus

- in lateral and AP

- use finger reduction tools and pass across fracture site to exact centre in AP and lateral

- bone reduction forceps

- blocking screws

- universal external fixation

- plate fibula



Fibular fixation



Peng et al. J Foot Ankle Surg 2021

- tibial IMN +/- fibular fixation

- meta-analysis of 4 trials, 283 patients

- tibial malalignment of 67% (126 / 189) in non fibular fixation group

- tibial malalignment of 20% (19/94) in the fibular fixation group

https://pubmed.ncbi.nlm.nih.gov/33218862/



Distal tibia fibularFibular fixation Distal tibia



Posterior malleolar fixation



Typically stabilize intra-articular fracture first



Posterior malleolusPosterior malleolus 2Posterior Malleolus 3



B.  Distal Tibial ORIF with plate



Indications

- too distal to nail

- very comminuted / unstable

- intra-articular extension



Distal tibial plate 1Distal tibial plate 2



Technique



1. Consider fixing the fibula

- will aid reduction / avoid malunion

- help control very unstable fractures



2. Anatomically contoured plates

- options of medial plate v anterolateral plate

- medial plate for varus deformity

- anterolateral plate for valgus deformity



Distal tibia plateDistal tibia plate 2Distal tibia plate 3Distal tibial plate 4



Distal tibia plate 5Distal tibia plate 6



Complications



Barcak et al. J Orthop Trauma

- single surgeon, extra-articular fractures

- 43 IMN and 43 MIPO plate

- both groups similar

- nonunion rate 7 - 8%

- malalignment 3%

- wound complication 3%

- 26% of IMN required distal locking screws removed

https://pubmed.ncbi.nlm.nih.gov/27101167/



Nonunion



Distal Tibial ORIF Nonunion



Plate and bone graft



Lin et al. Injury 2017

- 9 patients with distal tibia nonunion

- posteolateral approach to avoid poor anterior skin

- plate and iliac crest bone graft

https://pubmed.ncbi.nlm.nih.gov/28342545/



External fixator



Schoenleber et al. Foot Ank Int 2015

- 8 patients treated with ilizarov / taylor spatial frame

- hypertrophic nonunions

- callous distraction - allowed correction of deformity and shortening

- all achieve union at 6 months

https://pubmed.ncbi.nlm.nih.gov/25358806/



Malunion



Distal Tibial Malunion



Infection



Persistent infected nonunion post distal tibial nail

- nail removed

- irrigation +++

- ilizarov frame with immediate weight bearing

- union obtained, infection eradicated



Distal tibial infected non union with Ilizarov APDistal tibial infected non union with Ilizarov Lateral
