Shoulder Xrays

AP Shoulder



Technique

- in plane of thorax

- oblique of GHJ



Shoulder AP Xray



AP in plane of scapula



Grashey

- angle 45o lateral

- allows estimation of glenohumeral space



AP Plane Scapula



AP IR / ER



Demonstrates Hill Sach's and other humeral head morphology



Scapular lateral



Patient erect

- affected shoulder against plate

- rotate other shoulder 45o out of way

- beam aimed along spine of scapula



Scapular LateralScapula Lateral Posterior Shoulder Dislocation



Axillary lateral



Patient seated

- arm abducted

- plate under axilla

- beam angled down towards shoulder



Axillary Lateral XrayAxillary Lateral Posterior Subluxation



Supraspinatous outlet view



For acromial morphology and impingement



Similar to scapular lateral

- tilt beam caudal 10o



Supraspinatous Outlet View



West Point View



Variation axillary lateral

- tangential view anterior / inferior glenoid

- for bony bankart



Patient prone with arm hanging off bed

- plate superior to shoulder

- camera 25° cephalad to horizontal / 25° to long axis body



Westpoint view Hill Sachs



Garth View / Apical Oblique



True AP with 45o caudal tilt

- to show anterior / inferior capsule

- bony bankhart / Hill Sachs

- standing with plate behind joint

- 45° caudal tilt / 45° in coronal



Garth XrayShoulder Garth View



Stryker Notch view



Patient supine with cassette posterior to shoulder

- hand on head, elbow straight up

- beam 10o cephalic aiming at corocoid



Demonstrates Hill-Sach's



Stryker Notch View Hill Sachs



Zanca view



ACJ



Patient erect with cassette behind shoulder

- aim beam at ACJ 10 - 15o cephalic

- half strength to not overexpose ACJ



Zanca View



Serendipity view



SCJ



Technique

- prone with cassette under chest

- aim beam 40o cephalic



Sternoclavicular Joint Xray 1Sternoclavicular Joint Xrays 2
