Glenoid & Scapula Fractures

Glenoid Fractures



Indications for Surgery



ORIF

- > 5mm step

- > 1/4 glenoid rim and displaced



Ideberg Classification Intra Articular Fracture



Type I



Fractures of the Glenoid rim

I A anterior

I B posterior



Differentiate from small bony Bankart

- ORIF if > 1/4th or > 10 mm displaced (Neer)



Case 1



Glenoid Rim Fracture 1Glenoid Rim Fracture 2Glenoid Rim Fracture 2Glenoid Rim ORIF



Case 2



Glenoid FractureGlenoid Fracture CTGlenoid Fracture CT 2Glenoid ORIF



Case 3



Scapular fracture intraarticular glenoid axialScapula ORIF APScapula ORIF Lateral



Case 4



Glenoid Frac APGlenoid Frac AxialGlenoid Fracture CT



Type II



Transverse fracture through glenoid fossa

- inferior triangular fragment

- exits lateral border scapula



Glenoid FractureGlenoid ORIF



Scapula Fracture XrayScapula Fracture Intra articular CT SagittalScapula Fracture Intra articular Glenoid Coronal CT



Glenoid Fracture 1Glenoid Fracture 2Glenoid Fracture 3



Type III



Oblique fracture through the glenoid

- exiting through superior border of the scapula

- associated with AC fracture or ACJ dislocation

- includes the Coracoid



Type IV



Similar to II, larger superior fragment

- horizontal

- exiting thru the medial border of the blade



Glenoid FractureGlenoid Fracture 2Glenoid Fracture 3



Glenoid ORIFGlenoid ORIF 2Glenoid ORIF 3



Type V



Combination

- Va =IV+II

- Vb=IV+III

- Vc=IV+III+II



Type VI



Extensive comminution



Glenoid Malunion



Case 1

- untreated glenoid rim fracture

- patient with chronic instability

- treated with glenoid osteotomy



Glenoid Fracture Malunion CTGlenoid Osteotomy APGlenoid Osteotomy Lateral



Scapular Fractures



A.  Body



Often don't need ORIF
- well splinted by fascia / haematoma

- can treat non operatively



Scapula Body FractureScapular Body Fracture CT



Scapular Blade Fracture CTScapular Blade Fracture CT 2



Indications for surgery

- > 45 degrees of angulation of body



Scapular Body /> 45 degrees



B.  Neck



Indications for surgery

- > 450 angulation

- > 10 mm displaced (i.e. medial displacement



Case 1

- > 1 cm medial displacement

- ORIF via posterior / modified Judet approach



Scapula Neck FractureGlenoid Neck Fracture



Scapula ORIFScapula ORIF 3



Case 2



Glenoid DisplacementGlenoid Displacement CT



Glenoid ORIF 1Glenoid ORIF 2



C.  Spine



Scapula Blade Fracture CTScapula Spine Fracture





D.  Acromion



Spine scapula fracture



E.  Coracoid



Coracoid Fracture 1Coracoid Fracture 2



Coracoid Fracture CT 1Coracoid Fracture CT 2Coracoid Fracture CT 3Coracoid Fracture CT 4



Combined Glenoid and Scapula Fractures



Case 1

- displaced glenoid fracture and neck fracture

- ORIF both through posterior / Judet approach



Glenoid Scapular FractureComplex Scapular Fracture CT 1Complex Scapular Fracture CT2Complex Scapular ORIF
