Ankle Fracture

AnatomyDislocated Ankle



Bony

- 90% load through plafond to talus

- 10% load through lateral talofibular articulation



Ligaments



A.  Lateral Ligament Complex



ATFL (Anterior Talo-Fibular Ligament)

- tight in plantar flexion



CFL (Calcaneo-fibular ligament)

- slopes down & back

- tight in dorsiflexion



PTFL (Posterior Talofibular Ligament)

- scissors with Posterior Tibiofibular Ligament



B.  Medial Ligaments



Superficial Deltoid (SDL)

- origin medial tibia

- broad insertion talus / calcaneum / navicular

- resists hindfoot eversion



Deep Deltoid (DDL)

- tibiotalar

- key to stability / primary stabiliser of ankle

- resists talus ER

- if divided get abnormal ER of talus in plantar flexion



C.  Syndesmosis



Interosseous Ligament

- between AITFL and PITFL (anterior inferior and posterior inferior tibio-fibular ligament)



Biomechanics



ROM

- DF = 30°

- PF = 45°

- Rolls & slides to produce DF/PF



Plantarflexion

- deltoid ligament acts as a checkrein

- prevents ER of talus

- causes 5° IR talus



Dorsiflexion

- talus wider anteriorly 2.5 mm

- fibula moves laterally & ER to accommodate



Ramsey 1976

- 1mm talus shift = Contact area decreased by 40%

- non-physiological study

- jammed wedges in intact ankle



Ankle Fracture Classification



No system prognostic



1.  Weber ABC



A.  Fracture distal to syndesmosis

- stable / avulsion type fracture

- FWB



Weber A



B.  Fracture at level of syndesmosis

- syndesmosis intact

- ORIF if medial structures not intact

- xray below demonstrates Weber B with rupture deltoid ligament

- ankle unstable



Ankle Weber B Fracture



C.  Fracture above level syndesmosis

- syndesmosis at risk / must assume is torn

- medial structures often torn



Ankle Weber C Fracture



2.  Lauge-Hansen 1950



Two part



1.  Position of talus

- supination tenses lateral structures

- pronation tenses medial structures



2.  Direction of force

- rotation or translational injury



A. Supination-Adduction

Stage 1: Transverse fracture of lateral malleolus at or below the level of anterior talo-fibular ligament (Weber B)

Stage 2: Vertical fracture of medial malleolus (often a marginal impaction at medial edge of plafond)



Ankle Fracture Supination Adduction



B.  Supination-External Rotation (Most common - up to 85% all injuries)

Stage 1: Rupture of AITFL

Stage 2: Short oblique fracture of the lateral malleolus (Weber B) (stable)

Stage 3: Rupture of PITFL / fracture of posterior malleolus of tibia

Stage 4: Transverse fracture of medial malleolus (unstable)



Ankle Fracture Supination ER



C. Pronation-Abduction (Less than 5% of ankle fractures)

Stage 1: Rupture of the deltoid ligament or transverse fracture of the medial malleolus

Stage 2: Rupture of the anterior and posterior inferior tibiotalofibular ligaments or bony avulsion

Stage 3: Proximal fibula fracture (often butterfly)



Ankle Pronation Abduction



D. Pronation-External Rotation

Stage 1: Rupture of the deltoid ligament or transverse fracture of the medial malleolus

Stage 2: Rupture of the anterior inferior tibiotalofibular ligaments or bony avulsion

Stage 3: Spiral/Oblique fracture of the fibula above the level of the syndesmosis

Stage 4: Rupture of the posterior inferior tibiofibular ligament or fracture of the posterior malleolus



Ankle Fracture Pronation External Rotation



X-ray assessment



3 standard views



AP, lateral and mortise



Ankle AP XrayAnkle Mortise View



Mortise



Technique

- foot internally rotated

- AP projection

- should be symmetrical clear space around talus



Ankle Mortise View



1.  Lateral talar shift / increased medial clear space

- medial clear space > superior clear space

- should be < 4mm

- indicates injury to medial structures

- instability



Ankle Fracture Increased Medial Clear SpaceAnkle Fracture Increased Medial Clear Space 2



2.  Tibia / fibular overlap < 1mm / syndesmotic injury



Ankle Fracture Syndesmosis WidenedAnkle Diastasis



Incidence



Unimalleolar 70%

Bimalleolar 25%

Trimalleolar 7%

Open 2%



Management



Principles



Reduction

- protects skin medially

- conscious sedation in emergency department

- well moulded POP

- unstable ankles need monitoring for loss of reduction

- can need external fixation to maintain position



Ankle Fracture Severely Dislocated Dislocated Ankle Lateral



Timing

- operate when swelling reduced

- usually < 6 hours or 6 days

- higher risk with bimalleolar / 2 incision operations

- risk not being able to close wounds / infection



Long term results rely on

- reduction of talus under tibia

- mechanical stability

- degree of chondral damage



Medial ligament injury is the key to management



1.  Isolated Lateral Malleolar / Weber B Fracture



Ankle Fracture Isolated Weber BIsolated Fibula Fracture 3 mm displaced



Definition

- no medial fracture / no complete deep deltoid injury

- no increased medial clear space

- no instability on stress ER views

- no syndesmotic injury



Pathology



85% have no medial injury

- by definition have no talar shift



LM displacement not important if medial side not injured

- Biomechanical studies show Talus doesn't follow LM when axially loaded if medial ligament  intact

- Doesn't lead to altered biomechanics



There is no external rotation of the distal fragment

- its relationship to the talus is fixed

- the proximal fragment is internally rotated

- again, this does not alter the biomechanics



Diagnostic Dilemma / Is the deltoid ligament intact?



Examination



A.  Non tender / no bruising

- is intact

- non operative management



B.  Tender / bruising

- may be partially injury sprained / or completely ruptured and unstable

- inconclusive



Lateral BruisingMedial bruising



Xray



1.  Mortise view

- any increased clear space

- ORIF



2.  Stress views



Option A:  Gravity Stress View

- Patient lies injured side down, cross table xray

- see if medial clear space opens



Option B:  Valgus view

- lead gloves

- can be painful as patient has acute injury



Option C:  EUA



Results of Isolated Weber B Fibular Fracture



Results of surgical and non surgical management equally good

- Talus is stable if medial ligament is intact

- If  < 3mm fibula displacement, nil poor outcome



Non operative

- Kristensen and Hansen etal

- 95% good outcome non operatively

- no salvage operations required for post-traumatic arthritis



Operative

- 1-3% chance of serious infection

- more long term swelling



Management



Cast in Internal Rotation to reduce the deformity



2.  Bi Malleolar Injury



Types



A.  Medial Malleolus and Lateral Malleolus Fractured



Ankle Fracture Bimalleolar



B.  Deltoid tear + Lateral Malleolus Fractured



Ankle Fracture Weber B + Deltoid Ligament



If have talar shift, then by definition bi-malleolar injury

- must be an interruption to medial structures



Results



Superior results with operative management

- able to obtain and maintain anatomical reduction

- 90% good results



Closed treatment

- for elderly or medically unfit

- acceptable reduction / ankle internally rotated

- 60% good results



Surgery



1.  Weber B + Medial Malleolus fracture



Fibula

- interfragmentary lag screw

- derotation 1/3 tubular plate



Medial malleolus (dependant on fragment size)

- 2 partially threaded lag screws

- 1 screw and one k wire

- TBW



Screen syndesmosis

- should be stable with Weber B

- stress view (ER and dorsiflexion)

- cotton test (clamp on fibula and attempt to open syndesmosis under II)



Ankle Fracture Bimalleolar ORIFAnkle Fracture Bimalleolar ORIF



2.  Weber B + Deltoid Ligament



Ankle Weber B Deltoid Ligament InjuryAnkle Weber B Deltoid Ligament ORIF



A.  Manage Fibula as above

- ensure joint fully reduced



Ankle Fracture Fibula ORIF Increased Medial Clear Space



B.  Medial clear space remains open

- ensure fibular out to length and anatomical

- assess syndesmosis intact / reduce and fix

- if remains open, must be suspicious of OCD fragment or deltoid ligament blocking medial reduction

- may need to open medially



No evidence that repair of medial ligament improves results



3.  Tri-Malleolar Fracture



Posterior malleolus



Anatomy

- avulsion of PITFL



Ankle Fracture Small Posterior Malleolus Xray



Ankle instability results if

- > 1/3 articular surface (>30%)

- displacement of > 2mm

- risk posterior subluxation of the tibio-talar joint



Issue

- these can be highly unstable and require external fixation



Trimalleolar UnstableTrimalleolar Unstable



Ankle External Fixator APAnkle External Fixator Lateral



Indications to ORIF posterior malleolus

- usually get anatomical reduction after plating of LM

- ORIF if > 30% and > 2mm displaced



 Ankle Fracture Large Posterior Malleolus XrayAnkle Fracture Large Posterior Malleolus CT



Surgical Options



1.  Posterolateral approach to fibula

- enable AP clamp to reduce and hold fracture

- anterolateral approach

- front to back screws



2.  Formal posterolateral approach

- patient lateral or prone

- PA screws or buttress plate



Posterior Malleolus LargePosterior tibial buttress plate



Ankle Fracture Trimalleolar ORIFAnkle Fracture Trimalleolar ORIF Lateral



4.  Syndesmosis Injury



Ankle Fracture Clear Syndesmotic Injury



Definition



Disruption of syndesmosis between level of fracture and plafond

- distal tibia and fibular not connected and stable



Situations



A.  Weber C fracture

- extremely high risk

- almost always safer to ORIF



Ankle Weber C Syndesmotic InjuryAnkle Weber C Syndesmotic Screw



B.  Weber B fracture + medial column injury

- occasionally syndesmotic injury

- check intraoperatively



C.  Maisonnerve injury

- high fibula fracture

- medial clear space opening / deltoid injury

- need diastasis screw



Ankle Fracture Maisonnerve InjuryAnkle Fracture Maisonnerve Proximal Fibula



D.  Isolated Injury



Ankle DiastasisORIF Diastasis



Intraoperative tests



Cotton test

Stress test



Management



Reduction technique

- foot in neutral, clamp across medial and lateral malleolus

- don't reduce in plantarflexion as posterior talus is more narrow

- don't over reduce the joint

- check symmetrical joint space on mortise view



Diastasis Screw Fixation technique



1.  With other LM / MM fracture

- 1 or 2 screws

- 3 or 4 cortices

- 3.5 or 4.5 mm

- at level of epiphyseal scar



Ankle Fracture Diastasis Screw



2.  High Weber C fibula / Maisonnerve

- don't have to plate fibula

- ensure fibula out to length

- usually 2 screws


Post op



Need screw in for 8 - 10 weeks

- need to await ligament healing

- NWB

- usually remove screw as will break



Ankle Broken Diastasis Screws



5.  Medial Malleolar Fractures



Medial Malleolus Fracture



Management



Displaced

- ORIF

- 20% risk of non union



Undisplaced

- can usually manage in cast

- still small risk of non union



Approaches



AO posteromedial approach ankle

https://surgeryreference.aofoundation.org/orthopedic-trauma/adult-trauma/distal-tibia/approach/posteromedial-approach-to-the-distal-tibia



Fixation



A.  Large fragment

- 2 x screws



Ankle Fracture Medial Malleolus 2 Screws



B.  Small fragment

- screw + K wire

- TBW



Ankle Fracture Medial Malleolus TBW



C.  Plate

- vertical fractures



Medial Malleolus Plate



6.  Open Ankle Fractures



Presentations



Compound Ankle FractureMedial compound wounds



Clean & Closeable wound

- wound usually medial

- washout / ORIF / close



Dirty wound / wounds need skin cover

- external fixation

- wound management

- ORIF later



7.  DM



Risks

- amputation (6% open, 40% closed)

- infection

- malunion / non union / delayed union



Increased in patient with neuropathy and PVD



Management

- increase fixation

- double NWB times

- leave sutures in for twice as long



8.  Elderly / Osteoporotic



Issue

- bone very poor

- good fixation difficult



Ankle Fracture OsteoporoticAnkle Osteoporotic Fixation



Complication



Non-union

- uncommon

- Improve for up to 9 yrs



Medial Malleolus Non union



Swelling

- worse after ORIF

- continues > 3/12



Fibula malunion

- decreases tibiotalar contact by 30%

- correction <4 years = Good results



Infection 1-4%



Missed fractures

- plafond fractures

- chondral lesions (50%)

- anterior process calcaneum



RSD



Stiffness



OA



Ankle OA Post ORIF
