Coronoid Process Fracture

BackgroundClassification Coronoid Fractures



The coronoid is the most important portion of ulno-humeral articulation



Reasons

1.  Provides anterior buttress

2.  Anterior capsule and brachialis attach to coronoid

2.  Anterior band of the MCL attaches to it

- distally and medially on sublime tubercle



Instability rises and prognosis deteriorates according to the amount of coronoid process that is fractured



Fracture patterns



Transverse

Anteromedial facet fragment



Mechanism



Most commonly associated with elbow dislocations

Anteromedial facet fractures may be caused by varus / rotational force



Regan and Morrey Classification



Coronoid Process Classification



Type I

- usually stable

- shear fracture not avulsion fracture

- may rarely cause residual instability in elbow dislocation



Coronoid Fracture Type 1Coronoid Fracture Type 1 CT



Type II

- 50% coronoid

- elbow usually unstable

- lose attachment of capsule

- ORIF screws or sutures

- any ? about stability use hinged fixator



Coronoid Fracture Type 2



Type III

- > 50% coronoid

- Uncommon

- unstable as lose capsule +/- MCL with anteromedial fragment

- ORIF with screw / sutures / anteromedial buttress plate

- again may need hinged fixator



Type 3 Coronoid FractureCoronoid Fracture Type 3



Operative Management



Surgical approach



1.  Universal posterior approach

- if performing surgery for complex dislocation

- allows medial and lateral access to joint



2.  Lateral approach through radial head

- if excising radial head, then replacing



3.  Medial approach

- isolate and protect ulna nerve

- elevation of ulna origin of flexor pronator group anterior to FCU

- important if fracture is anteromedial



4.  Approach through fractured olecranon



Options



Type 1

- capsular suture repair



Type 2 / 3

A.  Screws (AP or PA)

B.  Pass sutures through capsule and tie over drill holes in ulna



Anteromedial fragment

- medial approach / buttress plate



Coronoid Process Buttress Plate



Unrepairable / unstable

- reconstruct with radial head, iliac crest, or allograft
